LG-100N机械测力计的详细资料

LG-100N机械测力计

LG 系列是一套出色而经济的解决方案,于拉伸压缩测试。这些机械测力计具有 2.25 英寸刻度盘,甚至在zui大极限负载时,依然可以轻易地手动安装灵活坚固的夹具。

拉断线缆和软管,并记录必要的zui大拉力。可用于开关测试或者安装在测试支架上检测激活刹车所必须的压力。

LG 系列主要特色:LG-100N机械测力计

- 三种分度单位(磅力、千克力和牛)
- 真正安全
- 峰值开关

LG Series Mechanical Force Gauge

The CHATILLON® LG Series mechanical force gauge is ideal for a wide range of force testing applications. Based on our popular DPP Series force gauge, the LG Series features a larger, 2.25-inch dial for improved resolution and readability, peak hold button, ergonomic shape and improved accuracy of +0.5% of full scale. The LG gauge is an excellent, economical solution for tensile or compression testing.
The durable, plastic housing fits naturally in the hand for a comfortable and firm grip even at maximum loads. Gauges may be mounted to a test stand for even greater control and consistent results in repetitive testing applications. Easy to read concentric dial measures clockwise only. Dial rotates 360-degrees for taring. A peak hold button captures peak readings and can be easily and quickly returned to zero. A mechanical overload feature protects the gauge from damage. Available in lbf, kgf or N units of measure. LG Series gauges come complete with protective carrying case and a set of stainless steel attachments.
A Certificate of Calibration with Data is supplied standard.

Features
n Three Graduation Styles
 - LBF
 - KGF
 - Newtons
n Tensile (Pull) and Compression (Push) Testing
n Peak Load Switch
n Tare Ring
n Intrinsically Safe
n NIST Calibration with Data
n 2 Year Warranty

Specifications
Accuracy: +0.5% of Full Scale
Overload Capacity: 110% of Rated Capacity
Maximum Overload: 150% of Rated Capacity
Tare Capacity: 10% of Rated Capacity
Dial Resolution: 0.5% of Full Scale
Deflection (Full Scale): 10mm (.394 inches)
Operating Temperature: 40°F to 110°F
 5°C to 45°C
Instrument Weight: 1.5 lbs (0.68 kg)
Shipping Weight: 8.4 lbs (3.80 kg)

该产品由深圳市银飞电子科技有限公司提供,销售商地址位于深圳市南山区前海路振业国际商务中心1206。请您仔细阅读产品使用说明书,正确使用。
