MT500 Series Mechanical Force Tester

The CHATILLON®MT500 Series mechanical test stand is an easy-to-use solution for force measurement applications up to 500 lbf (2.5kN) capacities. The test stand may be equipped with a quick-action lever or precision handwheel for controlling crosshead speed and travel. The test stand can be bench mounted， wall mounted or positioned horizontally. Vertical clearances are available from 750mm (29.5 inch) up to 1500mm ( 60 inch). Standard stroke is 6 inches (150mm)， although longer strokes can be accommodated as a special order.

The Series features an innovative design that maximizes working space and simplifies operation and maintenance. The single column design with 150mm (6 in) throat is ideal for large specimens. The removable platen is designed toaccommodate metric and imperial threaded fixtures. Special gauge adapter make gauge alignment automatic. Options include a digital travel indicator， capable of displaying travel up to 0.01mm (0.0005 inch) and column ruler which is graduated in millimeters and inches.

The Series includes hook， compression plate， adapters and gauge mounting hardware.

Standard Accessories
 Part No. Description
 SPK-FMG-012B Hook
 17012 Compression Plate， 3” Diameter
 P-10020 Thread Adapter， 5/16-18 to #10-32
 NC000714 Hex Key， 6mm
 3157 Set Screw， #10-32x3/4”
 13048 Coupling， 1/4-28 to 5/16-18
 ADT/0115 5/8” Eye End Adapter
